vitrified CBN grinding/polishing wheel for crankshaft, camshaft

Price:	300.0~2000.0 USD
Payment Terms:	T/T,WU
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: KO-CBN

Production Capacity: 1000 pcs/month

Delivery Date: 7-15 Days

Material: Cubic Boron Nitride

Abrasive Grain Sizes: 80#-2000#

Application: grinding crankshaft, camsha...

Certification: ISO 9001:2000

Means of Transport: Air

Packing: 1 pcs in per box

Brand Name: ko

Usage: grinding camshfat, cranksha...

Product: vitrified CBN grinding whee...

Package: one pcs in per box

Vitrified bond CBN Grinding wheel for crank shaft, cam shaft
Speeds up to 120m/s
CBN Grinding wheel for crank shaft,cam shaft

Vitrified Bond CBN Grinding Wheel

Vitrified CBN Grinding Wheel is your first choice to achieve the effect of high-speed, high-efficiency and high-precision. and they have been widely used in the processing of hydraulic tappets, Camshafts, Crankshafts, glibs, machine tool parts, and cutting tools. The manufacturing technique developed can be used to make grinding tools of all spections with a speed up to 120m/s.

The Grain Size Selection

The grain size is usually decided according to the requirements of the work-piece's surface roughness and processing efficiency. Furthermore, the affect of bond force and grinding mode (e.g. surface grinding, end grinding, cylindrical grinding, internal grinding etc.) should also be taken into account.

The relations between the grain size and the surface roughness of work-pieces are shown in the following table

Grain No.	Surface Roughness (Ra/μm)
70/80-100/120	1.6-0.8
100/120-170/200	0.8-0.2
170/200-230/270	0.4-0.2

The recommended grain sizes for different grinding processes are shown in the following table.

Rough Grinding	70/80-120/140
Medium Grinding	120/140-200/230
Fine Grinding	200/230--M22/36
Polishing	M22/36 ---

Grain Size range: usually select grain size of 100/120----200/230 for Vitrified bonded.

The requirements to the grinding machine

The requirement of the vitrified CBN grinding wheel to the grinding machine is very high. The grinding machine should posses high stiffness, perfect aseismatic performance and thermal stability. And its principle axis should posses high accuracy, high rotating speed, axial displacement less than 3 μm and radial run out less than 5 μm . The feeding amount should be even and accurate, and the minimum feeding amount less than 2 μm /time.

Dressing of vitrified CBN grinding wheel

Size

Outside Diameter	Ring Width	Thickness	Arbor
200	5/10
230	10
250	5/10
300	5/10
350	5/7/10
400	5/10	15-50	50-305
450	5/10
500	5/10
600	5/10
750	5/10
900	5/10
1065	5/10
All of the size according to the customer's requirement
